The TG13 Series is Aimlux’s value-driven LED flood light, designed to deliver exceptional luminous efficacy of ≥150 lm/W at a highly competitive price point. Built with a die-cast aluminum housing and rated IP66/IK08, the TG13 offers the reliability and performance needed for everyday outdoor lighting — without the premium price tag.
Whether you’re illuminating commercial facades, parking areas, or public spaces, the TG13-100 combines high light output, wide voltage compatibility, and a lightweight compact form factor that makes installation quick and straightforward.
The TG13-100 is a cost-effective LED flood light built for a wide range of outdoor lighting applications. Its die-cast aluminum housing delivers solid thermal performance and weather resistance, while the high-effacity LED module provides bright, uniform illumination at a fraction of the energy cost of conventional lighting.
Ideal for:
Every TG13 unit undergoes quality control testing including IP66 water jet test, IK08 impact verification, photometric performance validation, and burn-in aging test before shipment.
| Model Number | TG13-100 |
|---|---|
| Product Type | LED Flood Light |
| Rated Power | 100W (±5%) |
| Luminous Efficacy | ≥150 lm/W |
| Luminous Flux | ≥15,000 lm |
| Color Temperature | 6500K (±150K) |
| CRI (Ra) | ≥70 |
| Beam Angle | 90° (standard) |
| Input Voltage | 100–277V AC |
| Frequency | 50/60 Hz |
| Power Factor | ≥0.9 at rated voltage load |
| Ingress Protection (IP) | IP66 |
| Impact Protection (IK) | IK08 |
| Body Color | Black / Gray |
| Housing Material | High pressure die-cast aluminum |
| Surface Treatment | Powder coating (weather resistant) |
| Optical Cover | High-transmittance lens |
| Body Length | 320 mm (Without bracket) |
| Body Width | 400 mm (Without bracket) |
| Body Height | 55 mm |
| Weight (without bracket) | ≤3 kg |
| Operating Temperature | -20°C ~ +40°C |
| Operating Lifetime | ≥30,000 hours |
| Package Size | 360 × 250 × 450 mm |
| Quantity per Carton | 4 pcs |
| Mounting Option | Bracket mounting (adjustable angle) |
| Cable Entry | PG11 cable gland |
| Surge Protection | Built-in 6kV SPD |
| Warranty | 3 Years |
| Certification | CE, RoHS |
Get the complete technical datasheet for TG13-100 LED Flood Light
